Slurry Recovery System
Technical specification :
1.YHF6000: applicable for mixing equipment volume 3-6m³, collection barrel capacity 6m³, homogenization barrel capacity 4 m³, storage barrel capacity 5 m³.
2.YHF10000: applicable for mixing equipment volume 8-10 m³, collection barrel capacity 10 m³, homogenization barrei capacity 5 m³, storage barrel capacity 6 m³.
Product function
Residual pulp recovery system is to treat and reuse the residual pulp generated after centrifugation of spun piles. The process is as follows: The residual pulp will be poured into the residual pulp barrel after the centrifugation of spun piles is hanged by the crane. After a certain amount of residual pulp is collected in the residual pulp barrel, the residual pulp will be pumped through the pipeline to the homogenizing barrel through the pulp pump for homogenization.When the homogenization reaches a certain concentration, the homogenized residual pulp will be pumped through the pulp pump through the pipeline to the collection barrel for temporary storage.When the mixing station need residual pulp, then the residual pulp is pumped to the measuring hopper above the mixing station by the pulp pump through the pipeline, and the residual pulp is quantitatively added to the mixing station by the measuring hopper.
Product highlights
Achieve automatic control, improve the utilization rate of residual pulp, reduce the labor intensity of employees.
